adjustable retaining clamps

  caillau’s specific retaining clamp is made of a band with a circular part covered with a rubber cushion to receive the element to be clamped, and a clip to hold the assembly. this clamp is used to hold hoses or cables (power cords, metal hoses and pipe-ends, filters, etc.).

• absorbs vibration for the clamped elements.

• resists salt spray for over 1 000 hrs.

 • resists temperature (-30° to 100°c) and “automotive” fluids.

 • manual clamping (pressing the clamp into the holding clip).

• allows pre-tightening/positioning on the part to be clamped.

• allows assembly of the “p” clips on the vehicle at a different stage  than the assembly of the component to be retained.

• allows unclamping of the application without having to disassemble  the support.

• the same clamp can be used on applications with various diameters.

• is reusable (under normal use conditions).

• materials: stainless steel band and epdm cushion.

traditional retaining clamps

beyond its specific products, caillau also has a wide range  of “p” clips, from diameter 3mm to diameter 105mm.

band widths: 9.5 and 12.7mm, as well as other widths upon request.

materials:

- band: stainless steel, clad steel, aluminium

- cushion: epdm, silicone, fkm, …
